Description
Anodized 1 1/2″ wide aluminum frame, hollow tube side mold design, Duraflect® copper-free mirror with color coordinated glazing vinyl and aluminum Ultraglide® track and channel
• 4mm Duraflect® copper-free mirror
» Elimination of copper dramatically improves quality and life expectancy
» This creates a durable, superior grade mirror with exceptional quality
• 1 1/2” wide heavy-duty commercial quality anodized aluminum frame
• Aluminum track and channel
• Ultraglide® 2 1/4” deep felt-lined top channel
• Bottom rolled with jump-proof track
• Top channel and bottom track with finish to match
• 1 1/2” diameter wheels with hardened steel races and 5/32” ball bearings in extra-heavy 18 gauge steel housing
• Heavy gauge 6063 extrusions (6463 is polished for bright colors
• Side rails are hollow extrusions (tubular) for added strength
• Integrated handle in side rail
• Color coordinated glazing vinyl
• Duraflect® copper-free mirror panel has 400lb category II safety backing
• Standard sizes
» Width: 48”, 60”, 72”, 84”, 96”, 108”, 120”, 144”, 168” and 192”
» Height: 81” and 96”
• Custom sizes
» Maximum individual panel width is 60”
» Maximum opening height is 120”
• Adjustment range for opening height is up or down 1/2”
 |
 |
 |
 |
 |
 |
|
